With Trail Angel you can secure your child’s bike to yours and cycle together in total safety and tranquillity.

So simple to fit from the very first time, Trail Angel easily secures and adjusts with the turn of a knob.

  • No more troublesome
    initial adjustments based on the size of the child’s bike.
  • No more removal of parts from the child’s bike before it can be towed.
  • No more stopping to make adjustments during the early part of the ride.

It takes just 1 minute of your time to attach Trail Angel, so you can enjoy the rest of your time with your angel.

With Trail Angel you can allow your child to ride independently once you have reached a safe location. The device is extremely easy to hook and unhook and it can be folded back onto the adult bike to permit independent movement.

Once folded closed Trail Angel occupies little space so it is perfect to take on holiday with you.

You and your angel... The passion
We... The safety


Trail Angel è un prodotto certificato TUV GS

Available in 3 colours

art. 300/r - art. 300/g - art. 300/v

REQUIREMENTS OF THE BICYCLES
ADULT BIKE
Wheel diameter Minimum size: 635 mm (25")
Diameter and characteristics of the seat-post tube Min 25.4 mm (1"), Max 31.8 mm (1.25")
Precautions for use The use of non-metal seat posts is forbidden. Accessories or parts that may interfere with the operation of the tow-bar must never be used.
CHILD BIKE
Wheel diameter Minimum wheel size: Min 255 mm (10") Max 510 mm (20")
Diameter and characteristics of the handlebar columns Diameter min. 34mm (1.34"), max 38mm (1.50").
Ensure that the brake cable does not interfere with the child bike tow-bar connector.
Precautions for use If the bike is fitted with stabilizer wheels: turn them upwards or remove them altogether before using the child bike with the tow-bar. Accessories or parts that may interfere with the operation of the tow-bar must never be used.
REQUIREMENTS FOR THE CYCLISTS
ADULT CYCLIST
Basic skill Must be an adult and able to ride a bicycle with complete mastery of the same.
Equipment Must wear a helmet approved in accordance with the regulations in force.
CHILD CYCLIST
Basic skill The child must be able to grip the handlebar properly and, in any case, demonstrate a certain confidence in riding the bike and be capable of pedalling properly.
Equipment The child must wear a helmet approved in accordance with the rules in force while the use of adequate protection for the knees and elbows is also recommended. Make sure that the child wears clothing that is suitable for the weather conditions, in particular, make sure the child is suitably protected in the event of rain.
PERMISSIBLE MAXIMUM WEIGHTS
Adult's weight Must have sufficient weight for towing (minimum double the child's weight)
Child's weight Max 30 kg (66.14 lb)
Child bike weight Max 15 kg (33.07 lb)
Child bike weight
+ child's weight
In any case the towed weight must not exceed 45 kg (99.21 lb)
